Tank Components

QTS Heads

Customized to ensure structural integrity and ASME compliance. Tailored to your vessel’s pressure, size, and cleanability needs.

Flat Flanged

• Thickness: 14ga – ¼”

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”, 1″, 2″, 3″, 4″, 5″

• Diameter: 14″ – 168″

Dished Only

• Thickness: 12ga – ¼”

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Diameter: 18″ – 149″

• Dish Radius is equal to 100% of Diameter

Shallow Flanged & Dished

• Thickness: 14ga – 3/16″

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”, 1″, 2″, 3″, 4″, 5″, 6″, 7″, 8″, 9″

• Straight Flange: Up to 2″

• Diameter: 18″ – 147″

• Dish Radius is equal to 120-150% of Diameter

Standard Flanged & Dished

• Thickness: 14ga – 3/16″

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”, 1″, 2″, 3″, 4″, 5″, 6″, 7″, 8″, 9″

• Straight Flange: Up to 2″

• Diameter: 18″ – 147″

• Dish Radius is equal to 100% of Diameter

Dished & Flared

• Thickness: 14ga – 3/16″

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”

• Straight Flange: Up to 2″

• Diameter: 18″ – 120″

• Dish Radius is equal to 150% of Diameter

Reverse Flanged & Dished

• Thickness: 12ga – ¼”

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”, 1″, 2″, 3″, 4″, 5″, 6″

• Straight Flange: Up to 2”

• Diameter: 24″ – 108″

• Dish Radius is equal to 150% of Diameter

ASME Flanged & Dished

• Thickness: 14ga – 3/16″

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”, 1″, 2″, 3″, 4″, 5″, 6″, 7″, 8″, 9″

• Straight Flange: Up to 2″

• Diameter: 18″ – 147″

• Dish Radius is equal to 100% of Diameter

• Knuckle Radius is equal to 6%

ASME Flanged & Dished 10% Knuckle Radius

• Thickness: 7ga – 3/16″

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”, 1″, 2″, 3″, 4″, 5″, 6″, 7″, 8″, 9″

• Straight Flange: Up to 2″

• Diameter: 20″ – 90″

• Dish Radius is equal to 100% of Diameter

• Knuckle Radius is equal to 10%

ASME 80:10 Flanged & Dished

• Thickness: 7ga – ½”

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: 2″, 3″, 4″, 5″, 6″, 7″, 8″, 9″

• Straight Flange: Up to 2″

• Diameter: 18″ – 100″

• Dish Radius is equal to 80% of Diameter

• Knuckle Radius is equal to 10%

2:1 Elliptical

• Thickness: 7ga – ½”

• Material: 304, 304L, 316, 316L

• Finish: 2B, #4, MILL

• Knuckle Radius: ¾”, 1″, 2″, 3″, 4″, 5″, 6″, 7″, 8″, 9″

• Straight Flange: Up to 2″

• Diameter: 24″ – 54″

The Perfect Fit For Your Process

Precision‑formed stainless steel heads engineered to your exact specs, with sanitary finishes, 3‑A and ASME options, and compatibility with heat‑transfer surfaces.

Faster Lead Times & Local Support

We provide responsive communication, Wisconsin-based manufacturing, and collaborative design support—reducing turnaround time and simplifying the ordering process.

Built for Long-Term Durability

Ensuring resistance to pressure, thermal cycling, and demanding washdown environments.

Tank Head Quote Form

CONES

Conical and Toriconical

Our stainless steel tank cones deliver reliable strength, sanitation, and flow efficiency for demanding applications across food and beverage, dairy, brewing, pharmaceutical, and industrial processing.

Quality Materials

Fabricated from 304 or 316L stainless steel, with material thicknesses from 14 gauge to ¼ inch and finishes including 2B, #4, and mill for hygienic, durable performance.

Custom Configurations

Available in concentric or eccentric designs with customizable angles from 45° to 150° and diameters from ¾ inch to 150 inches, ensuring optimal drainability and seamless fit.

Engineered for Integration

Each cone is precision‑built to integrate smoothly into new builds or retrofit applications, providing consistent, long‑term reliability.

IMG_0969 square

Whether you are engineering a new sanitary tank, upgrading a processing system, or optimizing product flow, QTS provides high‑quality stainless steel cones to maximize efficiency, maintain compliance, and support superior production performance.

Learn About Our 3D Modeling Capabilities

SHELLS & WRAPS

QTS HTS

Heat Transfer Surface Integration

QTS integrates high‑efficiency heat transfer surfaces directly into our shells, wraps, heads, and cones to deliver precise temperature control throughout your process. Whether you need rapid heating, efficient cooling, or consistent product conditioning, our engineered surfaces are designed for maximum thermal performance and uniformity. Each heat transfer zone is custom‑built to your application—optimizing energy use, improving batch consistency, and ensuring reliable operation across even the most demanding sanitary environments. With seamless integration and fully weld‑finished construction, QTS heat transfer surfaces enhance overall system performance while maintaining the highest hygienic standards.

Energy Savings Potential

Integrating heat transfer surfaces directly into QTS shells, wraps, heads, and cones significantly improves thermal efficiency, allowing systems to reach target temperatures faster and with less energy input. By maximizing surface contact and promoting uniform heat distribution, these engineered zones reduce heat loss, minimize cycling, and optimize the overall performance of your heating or cooling system. The result is lower utility consumption, more consistent batch temperatures, and reduced operating costs over the life of the equipment. With smarter thermal transfer built into the vessel itself, your process runs more efficiently—saving energy without sacrificing precision or sanitation.

Tri-Clamp 3A Tank Vents

Durable. Cleanable. Food-industry ready.

QV3-3S | exterior

QV3-onTANK

Our 3A Tri-Clamp Tank Vents keep your product protected and your process running smoothly. Available capped or shrouded in 3″, 4″, and 6″ sizes, they’re engineered for reliable airflow on tank heads and in silo alcoves—where hygiene matters most.

Elevate Your Process

Explore our range of custom-engineered sanitary stainless steel tanks, crafted to meet your unique specifications. Whether you're in the food & beverage, dairy, chemical, brewing or pharmaceutical industry, our tanks ensure compliance with the highest standards while maximizing efficiency and cleanability. Partner with us for expert support and maintenance, safeguarding your investment for the long haul.
