Keep Your Process Moving with Reliable Pumps
Quality Tank Solutions offers a full line of high‑performance pumps and portable pump carts engineered for clean‑in‑place (CIP), product transfer, and sanitary processing applications. Built for durability, efficiency, and washdown environments, our pump solutions are designed to keep your operation running smoothly and safely.
Individual Pumps
Our wide selection of sanitary pumps for standalone installation or system upgrades. Whether you need centrifugal, positive displacement, or specialized stainless steel pumps, our team helps you select the right model for flow rate, pressure, temperature, and product handling requirements.
Portable CIP & Transfer Pump Carts
Our portable pump carts are built for mobility, reliability, and easy sanitation. Each cart features a rugged 304 stainless steel frame, full washdown capability, and a high‑quality centrifugal pump paired with a washdown‑rated motor and VFD. These systems are ideal for breweries, dairies, food processing facilities, and any application requiring flexible CIP or transfer pumping.
Standard Pump Cart Features Include:
- Topline C114 D‑Seal Centrifugal Pump (1.5″ x 1.5″ Tri‑Clamp)
- 1.5 HP Stainless Steel Washdown Motor
- Lenze NEMA 4X Washdown VFD (208–230V, single‑phase/three‑phase)
- 304 Stainless Steel Frame with formed parts basket
- Full washdown construction
- 30 ft power cable, end plug provided by customer
Custom Pump Solutions
Because Quality Tank Solutions is a complete custom fabrication shop, we can design pump carts or pump systems to your exact process needs. Our customization options include:
- Pump type and manufacturer
- Motor horsepower
- Voltage configuration
- Cable length and electrical connections
- Frame style, mobility options, and accessories
If your process requires something beyond our standard pump cart, our team will engineer the ideal solution—built to last and built for your operation.
New & Used Equipment For Sale
3-ft Custom Portable COP
Brand New, Manufactured by QTS, S/N- 17767- COP
Price for Tank Only: $4,785.00
Price for Full Assembly: $8,500.00
Tank Features
- Capacity: 35 gallons
- Construction: 12-gauge stainless steel, 32 µin Ra finish
- Design: Radius corners for easy cleaning
- Side jets with manifold
- 1.5” Tri-Clamp outlet with new manual locking butterfly valve
- Hose recirculation connections
- 5” locking casters for easy mobility
Available Add-Ons
Pump Cart – $3,150.00
- TOP-FLO 1.5 HP centrifugal pump
- Stainless steel motor, 3500 RPM
- MG seals (silicone carbide)
- 1.5” T/C inlet & outlet
- Stainless steel frame with basket and casters
- VFD (Variable Frequency Drive)
- 30’ cable (plug provided by others)
- Factory set and tested
Piping Manifold – $750.00
Cover, for additional cost
Heating Element, for additional cost
10-ft Fully Loaded Portable COP
Brand New, Manufactured by QTS, S/N- 14362-COP-2224-10L
Price for Tank: $29,995.00
Capacity: 250 gallons
Side jets with manifold
10‑gauge stainless steel, 32 µin Ra finish
Radiused corners for improved cleanability
4” x 2.5” sump outlet with screen and butterfly valve
5” locking casters for easy mobility
Pump Assemby:
- Fristam FPR 722 pump, 7.5 HP
- Full impeller
- Washdown‑duty motor
Control Panel
Electrical: 480V, 3‑phase, 60 Hz
Enclosure: NEMA 4X stainless steel, UL‑508A approved
Dimensions: 30″ H x 24″ W x 10″ D
- Thermal overload protection
- Control transformer
- Fuses
- Door‑mounted disconnect switch
- VFD with potentiometer for adjustable pump speed
- Anderson AJ300 2‑pen chart recorder (temperature & conductivity)
- FM conductivity sensor
- IFM RTD
Heating Element*
- ASB 24 kW heater
- Stainless steel seal‑tight housing integrated into the supply pump piping
- Easy‑access tri‑clamp maintenance connection
- Adjustable temperature set point
- Safety shutoff switch to protect heating elements
*Designed for maintaining temperature only
Available Add-Ons
Assist Cover, for additional cost
700-gallon Jacketed Tank
Brand New, Manufactured by QTS, S/N- 15899-20-MT
Price for Tank: $19,995.00
Tank Features
- Top Manway
- Heat Transfer Surface on 50% of Sidewall
- CIP Removeable Sprayball
- 15° Cone Bottom
- 1.5” Tangential Inlet
- 1.5” Tri-Clamp Outlet
- 58” OD x 112 ½” OAH
Available Add-Ons
Platform – $3,500.00
Agitation, for additional cost
Customizations to fit your needs, for additional cost
10-bbl Fermentation Tank
Used, Manufactured by QTS, S/N- 11246-10-FV-B
Price for Tank: $11,000.00
Tank Features
- Two Zones of Heat Transfer Surface on the Cone & Sidewall Piped to the Top Head
- 4” Hopping Port
- Racking Arm w/ Butterfly Valve
- Removable CIP Whirly Spray Device w/ Butterfly Valve piped to floor
- PRV
- Perlick Sample Valve
- 1.5” Tri-Clamp Outlet w/ Butterfly Valve
- 20% Freeboard (does not include the top headspace)
- The tank will be passivated before shipment
- 2-Year QTS Standard Warranty
Elevate Your Process
Explore our range of custom-engineered sanitary stainless steel tanks, crafted to meet your unique specifications. Whether you're in the food & beverage, dairy, chemical, brewing or pharmaceutical industry, our tanks ensure compliance with the highest standards while maximizing efficiency and cleanability. Partner with us for expert support and maintenance, safeguarding your investment for the long haul.
